SPECIFICATIONS |
Cell | Mono |
Weight | 25.5kg |
Dimensions | 2094x 1038 x 35mm |
Cable Cross Section Size | TUV: 4mm2 (0.006inches2)/UL: 12AWG |
No. of Cells | 144 (6x24) |
Junction Box | IP68 |
Cable Length | Portrait 300mm/Landscape 1200mm/Customized |
Packaging Configuration | 31pcs/Pallet, 726pcs/40ft Container |
ELECTRICAL PARAMETERS AT STC |
Rated Maximum Power (Pmax) [W] | 435 | 440 | 445 | 450 | 455 |
Maximum Power Voltage(Vmpp/V) | 40.3 | 40.5 | 40.7 | 40.9 | 41.1 |
Maximum Power Current(Impp/A) | 10.80 | 10.87 | 10.94 | 11.01 | 11.08 |
Open Circuit Voltage(Voc/V) | 49.0 | 49.2 | 49.4 | 49.6 | 49.8 |
Short Circuit Current(Isc/A) | 11.33 | 11.40 | 11.47 | 11.54 | 11.62 |
Module Efficiency [%] | 20% | 20.2% | 20.5% | 20.7% | 20.9% |
Power Tolerance | 0~+5W |
Temperature Coefficient of Isc [α_Isc] | +0.043%/°C |
Temperature Coefficient of Voc [β_Voc] | -0.26%/°C |
Temperature Coefficient of Pmax [γ_Pmp] | -0.36%/°C |
STC | Irradiance 1000W/m², cell temperature 25°C, AM1.5 |
