SPECIFICATIONS |
Cell | POLY |
Weight | 22kg |
Dimensions | 1956x 992 x 35mm |
Cable Cross Section Size | TUV: 4mm2 (0.006inches2)/UL: 12AWG |
No. of Cells | 72 (6x12) |
Junction Box | IP68, 3 diodes |
Cable Length | Portrait 300mm/Landscape 1200mm/Customized |
Packaging Configuration | 31pcs/Pallet, 816pcs/40ft Container |
ELECTRICAL PARAMETERS AT STC |
Rated Maximum Power (Pmax) [W] | 320 | 325 | 330 | 335 | 340 |
Maximum Power Voltage(Vmpp/V) | 37.5 | 37.7 | 37.8 | 38.0 | 38.2 |
Maximum Power Current(Impp/A) | 8.53 | 8.62 | 8.73 | 8.82 | 8.91 |
Open Circuit Voltage(Voc/V) | 44.6 | 44.9 | 45.5 | 46.1 | 49.9 |
Short Circuit Current(Isc/A) | 9.03 | 9.10 | 9.22 | 9.31 | 9.37 |
Module Efficiency [%] | 16.5% | 16.8% | 17.0% | 17.3% | 17.5% |
Power Tolerance | 0~+5W |
Temperature Coefficient of Isc [α_Isc] | +0.043%/°C |
Temperature Coefficient of Voc [β_Voc] | -0.26%/°C |
Temperature Coefficient of Pmax [γ_Pmp] | -0.36%/°C |
STC | Irradiance 1000W/m², cell temperature 25°C, AM1.5 |
