SPECIFICATIONS |
Cell | Mono |
Weight | 19kg |
Dimensions | 1640*992*35mm |
Cable Cross Section Size | TUV: 4mm2 (0.006inches2)/UL: 12AWG |
No. of Cells | 60 (6*10) |
Junction Box | IP68 |
Cable Length | Portrait 300mm/Landscape 1200mm/Customized |
Packaging Configuration | 31pcs/carton, 952pcs/40hq |
ELECTRICAL PARAMETERS AT STC |
Rated Maximum Power (Pmax) [W] | 270 | 275 | 280 | 285 | 290 |
Maximum Power Voltage(Vmpp/V) | 31.2 | 31.4
| 31.6 | 31.8 | 32.0 |
Maximum Power Current(Impp/A) | 8.65 | 8.76 | 8.86 | 8.96 | 9.06 |
Open Circuit Voltage(Voc/V) | 37.2 | 38.0 | 38.5 | 38.7 | 38.9 |
Short Circuit Current(Isc/A) | 9.06 | 9.18 | 9.29 | 9.38 | 9.47 |
Module Efficiency [%] | 16.6% | 16.9% | 17.2% | 17.5% | 17.8% |
Power Tolerance | 0~+5W |
Temperature Coefficient of Isc [α_Isc] | 0.043%/℃ |
Temperature Coefficient of Voc [β_Voc] | -0.26%/°C |
Temperature Coefficient of Pmax [γ_Pmp] | -0.36%/°C |
STC | Irradiance 1000W/m², cell temperature 25°C, AM1.5 |
